燃机GE涡轮IS220PAICH1A?336A4940CSP3风电通用IO模块控制系统

IS220PAICH1A GE MK VI

技术规格：

• IS220PAICH1A

• 通用电气

• MK VI

• 涡轮控制系统

• 印刷电路板

IS220PAICH1A 是通用电气或 GE Speedtronic MKVIe 燃气轮机控制系统的关键组件。

I/O 包包含两个以太网端口、一个电源、一个本地处理器和一个数据采集板。

IS200TBCIH1BBC 是一种称为接触端子板的设备。这是为 Mark VI 系列创建的 PCB。Mark VI 系列是由通用电气或 GE 组成的 Mark 系列的几个系列之一。开发这些系统是为了控制工业环境中燃气轮机和蒸汽轮机的所有操作。The IS200TBCIH1BBC is a long circuit board with a variety of different electronic components. Two (2) very big terminal blocks that are solid black take up the left half of the IS200TBCIH1BBC. These terminal blocks feature forty-eight (48) terminals made of silver metal. These terminals are identified by a series of numbers from one to forty-eight with twenty-four (24) in each terminal block. Directly to the right of the IS200TBCIH1BBC is a long line of circular capacitors. These capacitors are solid red. There are twenty-five (25) of these capacitors aligned next to these terminal blocks. Sitting on the right edge of the IS200TBCIH1BBC are three jack connector ports which are silver and black. Directly to the right of each of these connector ports is a very small integrated circuit labeled with the letter U. Two (2) other connectors which are white are centered at the top of the IS200TBCIH1BBC. Both of these connectors contain three (3) ports which can be used to connect other components to the IS200TBCIH1BBC. A very long line of tiny resistors is featured to the right side of the center of the PCB. This line spans almost the entire length of the IS200TBCIH1BBC.

下单请联系我们：程程15339539190(微信同号）
